Electrical Rating: 56 amp
Number of Main Contacts: 1-3 Poles
Available Main Contact Configuration: NO, NC, NO & NC
Operating Voltage (Thermal Rating): 500VDC (600VDC)
NO Continuous Contact Rating: 56A
NC Intermittent Contact Rating @ 500VDC (Dynamic Brake-Make Only): 105A
NC Intermittent Contact Rating @ 160VDC (Jogging-Break Only): 35A
Coil Voltage Options: 120VAC, 240VAC, 120VDC, 240VDC
Maximum Number of Auxiliary Contacts: 8
Available Auxiliary Contact Configuration: NO,NC,NO&NC
Auxiliary Contact Rating @ 120VAC (Continuous/Inrush): 6A/ 60A
Auxiliary Contact Rating @ 280VAC (Continuous/Inrush): 3A/ 30A
Auxiliary Contact Rating @ 480VAC (Continuous/Inrush): 1.5A/ 15A
Auxiliary Contact Rating @ 600VAC (Continuous/Inrush): 1.2A/ 12A
Average Contactor Closing Time: 33mSec
Average Contactor Opening Time: 30 mSec
Operating Temperature Range: -20C to +57C
Storage Temperature Range: -40C to +70C
* = Consult Factory for Custom Configurations
